STOP AND READ
BEFORE GOING ANY FURTHER.
This VATS key comes in 15 different values.
You must choose the correct value for the key to work.
- Each pellet or chip in a VATS key has a different OHMS value.
- If
you choose the incorrect VATS value, your key will turn in the ignition
but will not engage the alternator, fuel pump or starter, giving you
the symptoms of a dead battery.
- You can use a multi meter with an OHMS (K) setting on 20K to find your keys VATS value.
- Place
one lead from the meter on one side of the wire in the black pellet of
your key and the other lead on the opposite side of the same wire.
- A value will be shown on your multi meter.
- Use the OHMS readings below to determine which value you need.
- If your OHMS value doesn't match the charts number exactly, round it to the nearest number.
Example: Your key measures 1.180 OHMS.
The blank you most likely need is the number #5 key as it is closer to 1.130 OHMS than 0.887 OHMS (#4) or 1.470 OHMS (#6).
VATS values measured in (K) OHMS
- 0.403
- 0.523
- 0.681
- 0.887
- 1.130
- 1.470
- 1.870
- 2.370
- 3.010
- 3.740
- 4.750
- 6.040
- 7.500
- 9.530
- 11.800
Product Information
- Genuine ILCO brand key blanks
- Made in USA
- Nickel plated brass with black plastic head
- Sold Individually
Applications
This key blank fits various products by the following manufacturers
- Buick
- Buick LeSabre, 1992-1999
- Buick Park Avenue, 1991-1996
- Buick Reatta, 1990-1992
- Buick Regal, 1994-1997
- Buick Riviera, 1990-1994
- Buick Roadmaster, 1994-1996
- Cadillac
- Cadillac Allante, 1988-1993
- Cadillac Broughman, 1993-1996
- Cadillac Concours, 1990-1999
- Cadillac Deville, 1990-1999
- Cadillac Eldorado, 1988-2003
- Cadillac Fleetwood, 1993-1996
- Cadillac Seville, 1989-1996
- Chevrolet
- Chevy Camaro, 1989-2002
- Chevy Caprice, 1995-1996
- Chevy Corvette, 1986-1996
- Chevy Impala, 1995-1996
- Chevy Lumina, 1995-2001
- Chevy Monte Carlo, 1995-1999
- Oldsmobile
- Oldsmobile 88, 1992-1999
- Oldsmobile 98, 1991-1998
- Oldsmobile Cutlass Supreme, 1994-1998
- Oldsmobile Eighty Eight, 1992-1999
- Oldsmobile LSS, 1999
- Oldsmobile Ninety Eight, 1991-1998
- Oldsmobile Regency, 1991-1998
- Oldsmobile Toronado, 1990-1993
- Pontiac
- Pontiac Bonneville, 1992-1999
- Pontiac Firebird, 1988-2002
- Pontiac Grand Prix, 1994-1996
- Pontiac GTA, 1988
- Pontiac Trans Am, 1989-1990
Confirming the key you're choosing is correct
-
Information found above is to be used as a GUIDE ONLY.
-
Although the applications shown above will fit those that are listed, there may be similar models that use different key blanks.
-
To
ensure you buy the correct key blank, we strongly recommend comparing
groove patterns of your current key against the image shown above.
If
you're still not sure...
-
VIEW THIS KEY IN REAL SIZE
-
Actual size line drawings and groove pattern profiles are available in our manufactures directory.
To access this directory and view these drawings, follow the instructions on the Check the Profile page FIRST.
- Once you understand how to check the profile, Click Here to find this key under General Motors.
- Need more help? Let's help find your key.
Various key blank manufacturers may call this key by a different part number
Some examples are:
- A1
201-S,
201S, 202-S, 202S, 203-S, 203S, 204-S, 204S, 205-S, 205S, 206-S, 206S,
207-S, 207S, 208-S, 208S, 209-S, 209S, 210-S, 210S, 211-S, 211S, 212-S,
212S, 213-S, 213S, 214-S, 214S, 215-S, 215S
- Curtis
25101, 25102, 25103, 25104, 25105, 25106, 25107, 25108, 25109, 25110, 25111, 25112, 25113, 25114, 25115
- Ilco
B62-P-1, B62P1, B62-P-2, B62P2, B62-P-3, B62P3, B62-P-4, B62P4,
B62-P-5, B62P5, B62-P-6, B62P6, B62-P-7, B62P7, B62-P-8, B62P8, B62-P-9,
B62P9, B62-P-10, B62P10, B62-P-11, B62P11, B62-P-12, B62P12, B62-P-13,
B62P13, B62-P-14, B62P14, B62-P-15, B62P15
- Strattec
595511, 595512, 595513, 595514, 595515, 595516, 595517, 595518, 595519, 595520, 595521, 595522, 595523, 595524, 595525
Key Cutting
- This key needs to be cut before it will work.
- This key can be duplicated using a standard key cutting machine found at most hardware stores and locksmiths.
We're proud to sell American made ILCO brand key blanks.
While
other companies sell cheap overseas products, we're proud to sell high
quality ILCO brand key blanks made right in Rocky Mount North Carolina.
|
